Bike & Pedestrian Paths

Explore outdoor luminaires for cycle routes, footpaths and shared-use connections

Explore this family Start a project brief

Product familyBike & Pedestrian Paths

Products available4

Technical files and performance vary by selected configuration.Technical files

A practical starting point

Products in this family

Use the product detail pages to review the available application context, product information, and next-step enquiry path.

Bike & Pedestrian Paths

4 published products

View all products

Bike & Pedestrian Paths

BoxLED-152

Compact rectangular lighting for functional outdoor spaces BoxLED-152 uses a compact rectangular housing and a direct, architectural product form. The model sheet identifies stainless steel 201 and glass construction, IP66 protection and several LED/power configurations for BoxLED-152. Its small box-shaped head provides a distinct alternative to circular decorative families. Use the site and mounting plan to confirm the selected optics and controls, particularly where the lighting must serve both vehicle areas and pedestrian connections. Design and installation Stainless steel 201 and glass construction listed in the BoxLED-152 model sheet. IP66 protection and configuration-dependent IK09 / IK10 options listed. Type I-V or custom optical arrangements included in the reference. Power configurations listed for BoxLED-152 span 20-50 W, 50-90 W, 40-100 W and 80-150 W. Application routes Cycle routes, pedestrian paths and public squares Car parks and functional public areas Large areas, port and airport environments identified in the application portfolio Configuration reference The following values are listed in the supplied model or family reference. Options are not all included as standard; confirm the selected configuration. Body: Stainless Steel 201 and glass Electrical input: Voltage: 200-240 V AC Color temperature options: 2200-6500 K Ambient temperature: -40 to +55 deg C Control options: DALI, 0-10V, Astro Dim, Step Dim IP Rating: IP66 IK Rating: IK09/IK10 Surge-protection options: 10kV,25kV, 10kA Accessory/interface options: Photocell, NEMA Socket, Zhaga Technical pack and project quotation To specify BoxLED-152, request the model-specific dimensional drawing, selected optical data and electrical configuration. Share the application, mounting height and interface, quantity, control requirements and destination market with your enquiry. Final power, optics, finish, accessories and commercial terms are confirmed for the selected configuration. Certification documents, where required, should be requested for the exact product and market. A compact rectangular BoxLED luminaire for pathways, parking areas and functional public spaces.

View luminaire

Bike & Pedestrian Paths

512-HS

The suspended configuration of the 512 family 512-HS carries the circular 512 light-engine form into a suspended installation arrangement. It allows a project team to compare a hanging configuration with the post-top and conventional road-lighting alternatives in the same family. The 512 notes describe separable LED modules, a sealed enclosure and die-cast aluminum construction. Confirm the suspension interface, mounting dimensions and selected optics against the intended structure before specifying the exact model. Design and installation Suspended mounting arrangement within the 512 family. Circular die-cast aluminum body with separable LED modules. IP66 / IK09 ratings listed in the shared family reference. Control and color-temperature options are configuration-dependent. Application routes Cycle routes and pedestrian paths Public squares and parking areas Parks, communities and landscaped outdoor spaces Configuration reference The following values are listed in the supplied model or family reference. Options are not all included as standard; confirm the selected configuration. Body: Die-Cast Aluminum and PC Color temperature options: 2200-6500 K Ambient temperature: -40 to +55 deg C Control options: DALI, 0-10V, Astro Dim, Step Dim IP Rating: IP66 IK Rating: IK09 Surge-protection options: 10kV, 10kA Accessory/interface options: Photocell, NEMA Socket, Zhaga Technical pack and project quotation To specify 512-HS, request the model-specific dimensional drawing, selected optical data and electrical configuration. Share the application, mounting height and interface, quantity, control requirements and destination market with your enquiry. Final power, optics, finish, accessories and commercial terms are confirmed for the selected configuration. Certification documents, where required, should be requested for the exact product and market. A suspended 512-family LED luminaire for pedestrian routes, plazas and outdoor landscape environments.

View luminaire

Bike & Pedestrian Paths

Mantis-S

A single-arm Mantis configuration for the public realm Mantis-S introduces a single-arm installation form around the distinctive Mantis luminaire head. It is useful to compare with Mantis-D where the arm arrangement and the relationship between the luminaire and its support matter to the project. The family design notes identify outdoor road and public-space applications and an IP66 enclosure. Request the Mantis-S-specific mounting drawing and technical sheet before confirming power, dimensions or loading. Design and installation Single-arm mounting arrangement identified in the application portfolio. Distinct support geometry around the Mantis head. IP66 enclosure described in the Mantis family design notes. Model-specific dimensions, power and mounting details requested separately. Application routes Cycle routes and pedestrian paths Public squares, parks and parking areas Urban streets and commercial outdoor environments Technical pack and project quotation To specify Mantis-S, request the model-specific dimensional drawing, selected optical data and electrical configuration. Share the application, mounting height and interface, quantity, control requirements and destination market with your enquiry. Final power, optics, finish, accessories and commercial terms are confirmed for the selected configuration. Certification documents, where required, should be requested for the exact product and market. A single-arm mounting option in the Mantis family for pedestrian routes and outdoor public spaces.

View luminaire

Bike & Pedestrian Paths

Bollard

Directional bollard lighting for routes and landscape edges Bollard combines an aluminum upright body with a rotatable lamp head and flange-base mounting. The design notes identify it for villa gardens, residential walkways, hotel courtyards and campus landscapes. Its compact upright form offers a different installation route from taller pole-mounted families. Review the required direction of light, base fixing and surrounding site details, then request the exact dimensional and optical information for the selected configuration. Design and installation Aluminum body and rotatable head described in the design notes. Flange-base mounting and a sealed outdoor structure. Bollard model sheet lists an 8-20 W configuration. IP66 / IK09 ratings and available controls listed in the reference. Application routes Cycle routes and pedestrian paths Villa gardens, residential walkways and hotel courtyards Parks, campus landscapes, public squares and parking-area edges Configuration reference The following values are listed in the supplied model or family reference. Options are not all included as standard; confirm the selected configuration. Body: Die-Cast Aluminum and glass Color temperature options: 2200-6500 K Ambient temperature: -40 to +55 deg C Control options: DALI, 0-10V, Astro Dim, Step Dim IP Rating: IP66 IK Rating: IK09 Surge-protection options: 10kV, 10kA Accessory/interface options: Photocell, NEMA Socket, Zhaga Technical pack and project quotation To specify Bollard, request the model-specific dimensional drawing, selected optical data and electrical configuration. Share the application, mounting height and interface, quantity, control requirements and destination market with your enquiry. Final power, optics, finish, accessories and commercial terms are confirmed for the selected configuration. Certification documents, where required, should be requested for the exact product and market. An aluminum bollard luminaire with a rotatable head and flange-base mounting for gardens and pedestrian routes.

View luminaire

Questions to carry forward

What should you compare before choosing a luminaire?

Selection guidance updated October 21, 2026

Review the product selection guide

How should products in this category be compared?

A category is a starting point for selection, not evidence that every listed luminaire fits the same project. Compare the exact model, mounting interface, optical distribution, electrical supply and control option against the site brief. Request the relevant datasheet and project-specific photometric files before approving a substitution.

What information is needed for a product review?

A product review starts with the selected model and the application it must serve. Identify the site layout, intended quantity and destination market, then separate confirmed requirements from open questions. Availability, test documentation, optional features and delivery timing need written confirmation for the actual configuration.

Site layout, mounting height and spacing, operating environment, and the lighting task.
Required light distribution, control behaviour, supply voltage, and any existing installation constraints.
Destination market, quantity, project schedule, and the documents required for approval.
